Name: SQKLF6530 Compact Scribing Marking Machine
Brand: KINMARK

SQKLF6530 Compact Scribing Marking Machine

Compact Design for Limited Spaces

Compact scribing marking machine designed for automotive production lines, offering stable high-speed marking performance in limited installation spaces.

Inquire Now → Telephone Inquiry

12-Month Warranty

The complete machine is covered by a 12-month warranty, with professional technical support and long-term maintenance service.

Fast Response Service

We provide efficient after-sales support, remote diagnosis, and technical assistance to ensure continuous operation.

Installation & Commissioning

Our engineers provide equipment installation, commissioning, and operator training to help customers start production smoothly.

Product Description

The SQKLF6530 compact scribing marking machine is designed for automotive component production lines where installation space is limited. It provides stable, low-noise and permanent marking performance for high-volume manufacturing applications.

With a compact structure and flexible installation design, the machine can be fixed directly on production lines or integrated into dedicated workstations, helping manufacturers achieve efficient and reliable marking processes.

Compact Design:
Space-saving structure allows installation in narrow production areas and limited working spaces.

High-Speed Marking:
Achieves marking speeds up to 2.5 characters per second (character height: 5mm, width: 3mm), meeting high-cycle production requirements.

Servo Motor Drive:
Powered by a servo motor with closed-loop control, ensuring strong driving force, accurate positioning and stable operation.

Stable Transmission:
Precision screw transmission provides smooth movement, reduced vibration and long-term reliability.

Technical Specifications

Marking Area	65 × 30 mm / 65 × 115 mm / 115 × 115 mm
Marking Depth	0-0.3 mm (Depending on material)
Marking Speed	2.5 characters/s (Character height: 5 mm, Character width: 3 mm, Flat surface marking)
Marking Type	Pneumatic Scribing
Machine Weight	9.8 kg / 17.3 kg / 19.3 kg
Protection Rating	IP54
Controller	Super Scribing Servo Controller (GFHSF2B01) / Integrated Controller (GF920AU-SF)
